AGM GLOBAL VISION Clarion 640 Dual Focus 35/60mm 2-16x/3-24x Mag 640x512-Res SKU: 430111893

Description

CLARION 640 DUAL FOCUS 25/50MM 2-16X/3-24X THERMAL RIFLE SCOPE

The NEW Clarion dual base magnification thermal scope is one of the most technologically advanced thermal scopes in the world. The new Clarion scopes were meticulously designed to solve one of the biggest problems many night hunters face, which is selecting which lens size/sensor configuration will provide the optical base magnification and field of view for each hunter’s primary application. The Clarion alleviates this concern by incorporating a dual-lens optical system that has the ability to mechanically alternate between a 35mm lens or a 60mm lens. This feature alters the base magnification and field of view with no degradation of the image resolution!

With the Clarion 640, Night Hunters can now use the benefits of a 35mm lens with a base magnification of 2x and a wider FOV (12.5° × 10.0° or 65 ft @ 100 yards) then quickly switch to a 60mm lens with a base magnification of 3x and a narrower FOV (7.3° × 5.9° or 38 ft @ 100 yards) to really make sure your positive identification and shot placement is on point!

This dual base magnification flexibility is a new evolution in electro-optics and it will provide hunters with the versatility to optimize their optic for the specific geography and animals which they are hunting whether it be hogs in the eastern fields, or coyotes in the western deserts!

This new design is also paired with the most sensitive thermal sensor temperature rating in its class, coming it at a mind-bending sub-20 milikelvin.

Although the Clarion implements an advanced new optical system, they didn’t cut any corners with any of the design elements that hunters have come to expect from the AGM brand, including: high-quality 640x512 12-micron thermal sensor, removable rechargeable battery, up to 8.5 hours of continuous battery life on a single charge (2 batteries included), 10 internal reticle options, 5 different customizable zeroing profiles, 10 different brightness and contrast settings, wifi hotspot capability, built-in recording w/sound and image capture storage, AGM Connect app compatibility, 4 different reticle colors, 4 color palettes, 5 image sharpness settings and a high-quality American Defense mount which work well with both AR and bolt-action shooting platforms.

Warning: California's Proposition 65

FEATURES:

Dual focus objective lens - 35mm/60mm
12μm thermal detector
Superior sub-20 milikelvin thermal sensitivity
Fast 50Hz imaging
High resolution OLED display
Adjustable color palettes
Various reticle types and colors
1x, 2x, 4x, 8x digital zoom
On-board video/audio recording and image capture
Built-in EMMC storage (16 GB)
Shot Activated Recording (SAR)
Wi-Fi data transmission
Stadiametric rangefinder
Standby mode
8.5 hours battery life (depending on model)
External power supply compatibility
Waterproof & shockproof
5-year warranty

SPECIFICATIONS:

Flat Field Correction (FFC): Auto, Manual, External Correction
Palettes: Black hot, White hot, Red hot, Fusion
Dimensions: 254 × 80 × 68 mm (10.0 × 3.1 × 2.7 in)
Exit Pupil Diameter: 6 mm
Reticle: 10 types, 4 colors, on/off
Boresight Adjustment: Digital Controlled
Distance Measurement: Yes (Stadiametric)
Scene Mode: Cold, Warm
Picture In Picture Mode (PIP): Yes
Hotspot: Yes
Video Recording: Yes
Audio Recording: Yes
Magnification: 2× - 16× / 3× - 24×
Detector type: 12μm VOx Uncooled Focal Plane Array
Standby Mode: Yes
Refresh rate: 50 Hz
Resolution: 640 × 512
Detection Range (6' object): 1800 m/yd / 3000 m/yd
Lens system: 35 mm; F0.9 / 60 mm; F1.1
NETD: Less than 20 mK (25°C, F# = 1.0)
Field of view (H × X): 12.5° × 10.0° / 7.3° × 5.9°
Digital zoom: 1×, 2×, 4×, 8×
Diopter adjustment range: -5 to +5 diopters
Focusing range: 7 m to infinity / 10 m to infinity
Hot Track: Yes
Eye relief: 45 mm
Display: 0.39-inch, OLED, 1024×768
Storage: Built-in EMMC (16 GB)
Capture Snapshot: Yes
Battery Type: Replaceable and Rechargeable Li-ion Battery
Battery Life (Operating): ≥ 8.5 h (25°C, hotspot off)
External power supply: 5 VDC, 2 A, USB Type-C
Operating Temperature Range: -30°C to +55°C (-22°F to 131°F)
Weight: 0.84 kg (1.85 lb)
Protection Level: IP67

INCLUDED IN BOX:

Thermal Imaging Rifle Scope
Mount
Two Rechargeable Battery
Charger, USB Cable
Lens Cloth
Manual
Carrying Case

Specifications

Optic Resolution:

640x512

Battery Life (Minimum):

Frame Rate:

50

Battery Life (Maximum):

8.5

Thermal Range; Detection:

3000

Item Height (Inches):

3.100

Item Length (Inches):

10.000

Battery Type:

Rechargeable

Thermal Range; Recognition:

Item Weight (lbs):

1.850

Item Width (Inches):

2.700

Color:

Black

Objective Size:

Max Magnification:

24

Min Magnification:

2

Model Number:

Quantity:

1

Thermal Range; Identification:

Restrictions

Oversea shipping:

No

Dropship Item:

Ships from Manufacturer. Please allow additional processing time
