COMPACT ACOG® 1.5X24MM FIXED RIFLE SCOPE

If you’ve heard of the Trijicon ACOG® (Advanced Combat Optical Gunsight), you likely know about the legendary performance this platform offers. The ACOG 1.5x24 model, offers a battery-free dual illuminated reticle pattern that works in any lighting conditions, with the added freedom of eye movement afforded by a larger exit pupil and longer eye relief.

The Trijicon Compact ACOG Mount w/ Q-LOC™ Technology features a Mil-Spec drop test rated 6061-T6 aluminum design, with an easy to use one handed tool less mounting system. The spring-loaded design allows for constant retention and maintaining of zero even if the knobs are not tightened.

The mount boasts a low weight and low profile design with superior return to zero performance and is compatible with any Mil-Spec or NATO Picatinny rail.

- Matte black anodized finish

- Made in the USA

Torque Spec (to rail):

• Spring Tension Only: 12-16 in. / lbs.
• Can be Tightened To: 44-66 in. / lbs

FEATURES:

ALWAYS ON, ALWAYS READY

Most ACOG® models are battery free, featuring a tritium/fiber optic illuminated reticle that automatically adjusts the brightness based on available light.

TAKE CONTROL

Several ACOG models are designed with a user adjustable brightness setting powered by a single AA battery. The 3.5x35 LED and 4x32 LED models both offer six adjustable brightness settings.

RUGGED, RELIABLE HOUSING DESIGN

Fixed-power design allows for minimal moving parts to create a nearly indestructible sighting system.

“BOTH EYES OPEN” DESIGN

“Both eyes open” shooting using Trijicon's Bindon Aiming Concept™ (BAC) feature allows for improved situational awareness.

OUTSTANDING CLARITY

The quality of the glass and multi-coated lenses maximize light-gathering capabilities and clear field of view with zero distortion.

EXACT TARGET DISTANCES & HOLDS

Most ACOG models feature a bullet drop compensating and target-ranging reticle for decisive aiming.

COMBAT PROVEN

No other magnified optic has been used more in combat than the ACOG.

SHOCK-RESISTANT

Proven to withstand recoil from a .22LR to a .50BMG and everything in between. Easily passes U.S. Military drop test requirements.

WATERPROOF

Exceptional waterproof performance that exceeds military standards. Dry nitrogen-filled to eliminate fogging. This optic is tested to withstand and perform in extreme cold and heat with dry-nitrogen filled housing that mitigates fogging.

INCLUDED IN BOX:

• Trijicon Q-LOC™ Technology Mount
• Scopecoat
• LENSPEN (TA56)
• Trijicon Logo Sticker (PR15)
• ACOG Manual
• Warranty Card

SPECIFICATIONS:

• LENGTH: 5.8”
• WIDTH: 2.1
• HEIGHT: 2.6
• MAGNIFICATION: 1.5x
• RETICLE PATTERN: Triangle
• ILLUMINATION SOURCE: Fiber Optic & Tritium
• EXIT PUPIL: 3.6 in. (91.44mm)
• FIELD OF VIEW (feet): 25.6 ft. @ 100 yds. (8.53m @ 100m)
• HOUSING MATERIAL: Forged Aluminum
• WEIGHT: 8.4oz (238.14g)
• OBJECTIVE SIZE: 24mm
• DAY RETICLE COLOR: Red
• NIGHT RETICLE COLOR: Red
• EYE RELIEF: 3.6 in. (91.44mm)
• FIELD OF VIEW (degrees): 4.9°
• FINISH: Matte Black
• POWER SOURCE: Fiber Optic & Tritium
• ADJUSTMENT: 2 clicks per inch @100 yards
• BINDON AIMING CONCEPT™ (BAC): Yes
• MOUNT: Trijicon Q-LOC™ Technology Mount
